Mimaki CG-160FXII Plus Vinyl Cutter
The Mimaki CG-160FXII Plus is a higher-end roll cutter built around long accurate tracking, continuous crop-mark detection, and FineCut integration for professional print-and-cut workflows. It is a strong choice for sign, label, and contour-cut applications that demand stable production on wider media.
- Continuous crop-mark detection for long print-and-cut runs
- Long accurate tracking
- FineCut workflow support
- Wider 64-inch class format for production graphics
Specifications
| Specification | Details |
|---|---|
| Sheet Width | CG-75FXII Plus: 3.54"~40.9" CG-130FXII Plus: 3.54"~62.0" CG-160FXII Plus: 3.54"~74" |
| Cutting Area | CG-75FXII Plus: 29.9" x 167' CG-130FXII Plus: 51.2" x 167' CG-160FXII Plus: 62.9" x 167' |
| Maximum Speed (Cutting/Moving) | 39.3"/s / 55"/s (in 45° direction and pen-up state) |
| Adjustable Cutting Speed Range | CG-75FXII Plus: 0.39"–3.94"/s: 0.39" step adjustment CG-130FXII Plus: 3.94"–19.68"/s: 2" step adjustment CG-160FXII Plus: 19.68"–39.37"/s: 3.94" step adjustment |
| Mechanical Resolution | 5 μm |
| Acceptable Sheet | Vinyl up to 0.01" thickness, fluorescent type vinyl, or reflective sheet |
| Dimensions (W × D × H) | CG-75FXII Plus: 50.5" × 27.5" × 47.9" CG-130FXII Plus: 71.8" × 27.5" × 47.9" CG-160FXII Plus: 83.6" × 27.5" × 47.9" |
| Weight | CG-75FXII Plus: 104 lbs CG-130FXII Plus: 137 lbs CG-160FXII Plus: 154 lbs |
| Interface | RS-232C, USB |
* CG-75FXII Plus and CG-130FXII have been discontinued by Mimaki
